Applications
- Level measurement in chemically aggressive environments
- Food and beverage processing
- Proximity sensing
- Obstacle avoidance
Highlights
- Best Operating Frequency: 30 kHz, ±4%
- Minimum Transmit Sensitivity at Best Transmit Frequency: 105 dB re, 1µPa/V at 1 m
- Minimum Receive Sensitivity at Best Receive Frequency: -155 dB re 1V/µPa
- Minimum Parallel Resistance: 700 Ω, ±30%
- Minimum and Maximum Sensing Range*: 60 cm to 30 m
- Typical Sensing Range: 80 cm to 25 m
- Free (1 kHz) Capacitance: 5,700 pF, ±20% pF
- Beamwidth (@ -3 dB Full Angle): 12°, ±2°
- Maximum Driving Voltage (2% Duty Cycle Tone Burst): 2,200 Vpp
- Operating Temperature: -40°C to 90°C
- Weight: 800 g
- Housing Material: Kynar® 720
- Acoustic Window: Kynar® 720
*Pulse-Echo Mode. Minimum and maximum ranges are best case scenarios. Actual range may vary, depending on drive circuitry and signal processing.
Features
- Rugged sealed construction
- Housing design will accommodate transceiver and signal processing electronics
- Standard internal shielding
Options
- Cylinder housing available with mounting cap kit
- Complete assembly available with standard cable lengths
- 10 KΩ thermistors for temperature compensation
- FM approved
- Mounting cap available in BSP, NPT, or M32 threads
