Applications
- Level measurement in chemically aggressive environments
- Food and beverage processing
- Flow monitoring
Highlights
- Best Operating Frequency: 50 kHz, ±4%
- Minimum Transmit Sensitivity at Best Transmit Frequency: 105 dB re, 1µPa/V at 1 m
- Minimum Receive Sensitivity at Best Receive Frequency: -170 dB re 1V/µPa
- Minimum Parallel Resistance: 350 Ω, ±30%
- Minimum and Maximum Sensing Range*: 30 cm to 15 m
- Typical Sensing Range: 35 cm to 10 m
- Free (1 kHz) Capacitance: 5,000 pF, ±20 pF
- Beamwidth (@ -3 dB Full Angle): 10°, ±2°
- Maximum Driving Voltage (2% Duty Cycle Tone Burst): 1,000 Vpp
- Operating Temperature: -40°C to 90°C
- Weight: 250 g
- Housing Material: Kynar® 720
- Acoustic Window: Kynar® 720
*Pulse-Echo Mode. Minimum and maximum ranges are best case scenarios. Actual range may vary, depending on drive circuitry and signal processing.
Features
- Rugged one-piece PVDF housing is U.S. FDA compliant
- Threaded design allows for installation in various applications
- Standard internal shielding
- 8 mm M3 PCB standoffs
Options
- Nut—2” BSP thread
- Complete assembly available with standard cable lengths
- 10 KΩ thermistors for temperature compensation
- FM approved
- 12 mm extension sleeve
- Mounting cap available in BSP, NPT, or M32 threads
