Applications

• Commercial Fishing
• Shallow and coastal survey

Features

• Two broadband arrays minimize ringing and allow sharp, crisp acoustic pulses and excellent clarity
• Narrow beams and low sidelobes provide clear bottom detail
• Matching transformers provide pure, resistive load
• Can be mounted on a towed body, directly to a wood, steel, or fiberglass hull (can also be mounted as an in-hull in a fiberglass hull for precise echosounding)
• Streamlined shape minimizes drag
• CHIRP-ready
• Seamless, SEALCAST™, urethane housing for long life underwater
• Exclusive Transducer ID™ technology
• High precision temperature probe

Specifications

• Weight: 10 kg (22 lb)
• Acoustic Window: Urethane
• Cable Type: C-44-02 Three shielded twisted pair (two 2-18 AWG and one 2-22 AWG) with foil and braided shield overall, black TPR jacket, 11 mm (7/16”) diameter
