Features
- High—CHIRPS from 130 kHz to 210 kHz, 15° to 9° beamwidth
- Available in 0°, 12°, or 20° tilted versions
- 80 kHz of total bandwidth from one transducer
- Depth & fast-response water-temperature sensor
- Steel transducer housing
- Boat Size: Up to 11 m (36’)
- Hull Type: Steel or aluminum
Specifications
- Hull Deadrise: Up to 28°
- Acoustic Window: Urethane
- Weight: 2.7 kg (6 lb)
