Tasks and applications
- Surfactant development
- Optimization of spray processes
- Development of washing and cleaning processes
- Optimization of painting and printing processes
- Checking the surfactant content in galvanic baths and cleaning baths
Measuring methods and options
- Measurement of surface tension as a function of surface age
- Long-term measurement of surface tension at constant surface age
- Determination of adsorption coefficient and diffusion coefficient
- Calculation of the surface tension of the solvent and the equilibrium surface tension (extrapolation in accordance with Hua & Rosen)
- Temperature control from -10 to 100 °C, temperature measurement with internal sensor
Technical data
| Measuring range | 10 to 100mN/m |
| Surface age | 5 to 200,000 ms |
| Resolution Surface tension Temperature |
0.01 mN/m 0.01 °C |
| Temperature range | -10 to 100 °C |
| Dimensions | 300 × 380 × 590 mm (W × D × H) |
| Weight | 13 kg |
