Tasks and applications
- Emulsifiers in the pharmaceutical and cosmetics industry
- Food production
- Tertiary oil recovery (Enhanced Oil Recovery, EOR)
- Cleaning
- Surfactant development
- Investigation of fuel-water mixtures
Measuring methods and options
- Measurement of dynamic interfacial tension between two liquids with
free assignment of drop phase and bulk phase - Measurement of surface tension of a liquid
- Temperature control from -10 to 90 °C
Technical Data
| Measuring range | 0.1 to 100 mN/m |
| Measurement resolution | 0.001 mN/m |
| Repeat accuracy (rel. standard deviation at 45 mN/m) |
0.2% |
| Flow rate | approx. 0.03 to 2000 µL/min |
| Dosind feed resolution | 0.1 µm |
| Temperature range | -10 to 90 °C |
| Dimensions | 240 × 280 × 455 mm (W × D × H) |
| Weight | 13 kg |
