- Model NO.: Mitech Electric (Hydraulic) Impact Specimen Notch
- Trademark: MITECH
- Origin: China
Product Description
Impact specimen notch broaching machine is the sole tool that can process qualified specimen notches other than the optical profile grinder. Due to the principle of one-step forming, notches processed by it have good identity. The products of this series can currently be classified into the following types domestically: Manual impact specimen notch broaching machine (single-blade), electric impact specimen notch broaching machine (double-blade) and hydraulic electric impact specimen notch broaching machine (double-blade). This product can meet the requirement specified in GB/T 229-2007 Metallic materials -Charpy pendulum impact test method. If the structural form is changed and important relevant parts are replaced, international standards such as ASTM, E23-02A, EN10045, ISO148 and ISO083 can be met.
| Shape of specimen notch | Vtype, Utyoe(2mm type as standard, 3, 5mm type optional) |
| Dimension of processed specimen | 10(7.5, 5)(× 10× 55) 10 (7.5, 5)× 10× 55 |
| Cutting method | Electric |
| Broach travel | 350mm |
| Broach material | W18Cr4V |
| Power supply | 380V, 0.37KW |
| Overall dimension | 580× 400× 1140mm |
| Weight | 180Kg |
| Note: This parameter list is only for information and is subject to change without notice. The real objects prevail for the products of our company. | |
