- Model NO.: HR-150A
- Trademark: Mitech
- Origin: Beijing, China (Mainland)
- HS Code: 902410200
Product Description
Rockwell Scales HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK
Initial Testing Force 10kgf 98N
All Testing Force 60kgf (588N), 100kgf (980N), 150kgf (1471N)
Indication of Hardness Value Dial
Overall Dimension 520*240*700mm
Net Weight 80kg
Max Height of Speciment 170mm
Max depth of speciments 165mm
Carried Standard GB/T230(1.2) Chinese Standard.
Initial Testing Force 10kgf 98N
All Testing Force 60kgf (588N), 100kgf (980N), 150kgf (1471N)
Indication of Hardness Value Dial
Overall Dimension 520*240*700mm
Net Weight 80kg
Max Height of Speciment 170mm
Max depth of speciments 165mm
Carried Standard GB/T230(1.2) Chinese Standard.
| Rockwell Scales | HRA, HRB, HRC, HRD, HRE, HRF,HRG,HRH,HRK |
| Initial Testing Force | 10kgf (98N) |
| All Testing Force | 60kgf (588N), 100kgf (980N), 150kgf (1471N) |
| Indication of Hardness Value | Dial |
| Overall Dimension | 520×240×700mm(L×W×H) |
| Net Weight | 80kg |
| Max Height of Speciment | 170mm |
| Max depth of speciments | 165mm |
| Carried Standard | GB/T230(1.2) Chinese Standard |
| Standard Accessories | Diamond Rockwell Indenter, Diameter 1.5875mm Hard Alloy Steel Ball Indenter, Large Testing Table , Medium Testing Table and Vshaped Testing Table, HRC and HRB Hardness Blocks. |
