RETSCH Horizontal Sieve Shaker AS 400 control
Pengiriman :
3 hari sejak pembayaran
Lokasi :
Jawa Barat - Bekasi
Update Terakhir :
19-07-2016 09:57
Dapatkan Spesifikasi Harga
RETSCH Horizontal Sieve Shaker AS 400 control Produk Terbaik dari
ANDALAN PRIMA SEJAHTERA LABORATORY EQUIPMENT, CHEMICAL, GLASWARE, MEASURING AND TEST
Detail Produk
Product Advantages
- sieving with circular sieving motion according to DIN 53477
- excellent separation efficiency even with short sieving times
- sieve stack up to 450 mm height
- free digital adjustment of all process parameters (time, speed or sieve acceleration, interval)
- memory for up to 9 SOPs
- interval operation
- optional software EasySieve for control through RS232 serial interface, easy evaluation and documentation of results
- fulfils all criteria for measuring equipment related to ISO 9001
- maintenance-free
- easy operation, ergonomic design
Features
| Applications |
separation, fractioning, particle size determination |
| Field of application |
agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
| Feed material |
powders, bulk materials |
| Measuring range* |
45 µm - 63 mm |
| Sieving motion |
horizontal circular motion |
| Max. batch / feed capacity |
5 kg |
| Max. number of fractions |
7 / 9 / 17 |
| Max. mass of sieve stack |
15 kg |
| Speed |
digital, 50 - 300 min-1 |
| Time display |
digital, 1 - 99 min |
| Interval operation |
1 - 10 min |
| Storable SOPs |
9 |
| Suitable for dry sieving |
yes |
| Suitable for wet sieving |
- |
| Serial interface |
yes |
| Including test certificate / can be calibrated |
yes |
| Suitable sieve diameters |
100 mm / 150 mm / 200 mm / 203 mm (8") / 305 mm / 315 mm / 400 mm |
| Max. height of sieve stack |
450 mm |
| Clamping devices |
"standard", "comfort", each for dry sieving |
| Protection code |
IP 54 / IP 20 |
| Electrical supply data |
100-240 V, 50/60 Hz |
| Power connection |
1-phase |
| W x H x D |
540 x 260 x 507 mm |
| Net weight |
~ 70 kg |
| Documentation |
Operation & Application Video |
| Standards |
CE |
