| Applications |
pulverizing, mixing, homogenizing, colloidal milling, mechanical alloying |
| Field of application |
agriculture, biology, Chemistry, construction materials, engineering / electronics, environment / recycling, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
| Feed material |
soft, hard, brittle, fibrous - dry or wet |
| Size reduction principle |
impact, friction |
| Material feed size* |
< 4 mm |
| Final fineness* |
< 1 µm, for colloidal grinding < 0.1 µm |
| Batch size / feed quantity* |
max. 2 x 50 ml |
| No. of grinding stations |
2 |
| Speed ratio |
1 : -2 |
| Sun wheel speed |
100 - 650 min-1 |
| Effective sun wheel diameter |
157 mm |
| G-force |
37.1 g |
| Type of grinding jars |
"comfort", optional areation covers, safety closure devices |
| Material of grinding tools |
hardened steel, stainless steel, tungsten carbide, agate, sintered aluminium oxide, silicon nitride, zirconium oxide |
| Grinding jar sizes |
12 ml / 25 ml / 50 ml / 80 ml / 125 ml |
| Setting of grinding time |
digital, 00:00:01 to 99:59:59 |
| Interval operation |
yes, with direction reversal |
| Interval time |
00:00:01 to 99:59:59 |
| Pause time |
00:00:01 to 99:59:59 |
| Storable SOPs |
10 |
| Measurement of input energy possible |
yes |
| Interface |
RS 232 / RS 485 |
| Drive |
3-phase asynchronous motor with frequency converter |
| Drive power |
750 W |
| Electrical supply data |
different voltages |
| Power connection |
1-phase |
| Protection code |
IP 30 |
| Power consumption |
~ 1250 W (VA) |
| W x H x D closed |
630 x 468 x 415 mm |
| Net weight |
~ 72 kg |
| Standards |
CE |
| Patent / Utility patent |
SafetySlider (DE 202008008473) |
