Product Description
CAT IV 600V, CAT III 1000V
3-3/4 digit LCD Backlit display with maximum reading of 4000.
Analog Bargraph.
AC voltage range: 0 to 750V.
AC current range: 0 to 1200A.
Peak Hold, Data Hold, Min/Max.
Test Ranges: ACV, ACA, DCV, Resistance, Frequency, Diode, Continuity.
Work Light.
Auto Power Off.
Double injection outer case.
|
Maximum Current |
1200 Amps |
|
Display |
4000 counts |
|
Max. Conductor Size |
52mm |
|
AC Current |
0.01A to 1200A |
|
AC Voltage |
0.1V to 750V |
|
DC Voltage |
0.1V to 1000V |
|
Resistance |
0.1Ω to 4000Ω |
|
Continuity Buzzer |
Yes |
|
Diode |
Test voltage |
|
Frequency |
1Hz to 400KHz |
|
Analog Bargraph |
Yes |
|
Backlit Display |
Yes |
|
Work Light |
Yes |
|
Autoranging |
Yes |
|
Auto Power Off |
Yes |
|
Peak Hold |
Yes |
|
Min/Max |
Yes |
|
Dimensions |
266mm (L) x 91mm (W) x 22mm (D) |
