Product Description
CAT IV 600V
LCD display with maximum reading of 6000, plus decimal point.
Analog Bargraph.
AC voltage range: 0 to 600V.
DC voltage range: 0 to 600V.
Auto power off (15 minutes).
Frequency measurement.
AC and Frequency measurement with only one test lead.
Phase sequence test.
Phase conformity test.
Continuity test.
Double injection outer case.
Specification
|
Display |
6000 counts |
|
Overvoltage Category |
CAT IV 600V |
|
AC Voltage |
1.5V to 600V ±(1.5% of rdg + 5 dgts) |
|
DC Voltage |
1.5V to 600V ±(0.8% of rdg + 1 dgt) |
|
Resistance |
1Ω to 1499Ω ±(1.0% of rdg + 5 dgts) |
|
Continuity Buzzer |
Yes |
|
Phase Test |
Test voltage 100 to 600 volts |
|
Frequency |
0.1Hz to 69.9Hz ±(1.0% of rdg + 2 dgts) |
|
Autoranging |
Yes |
|
Auto Power Off |
Yes |
|
Data Hold |
Yes |
|
Auto Power Off |
Yes |
|
Dimensions |
200mm (L) x 51mm (W) x 30mm (D) |
|
Weight |
150g approx. |
